airMAX PrismStation AC 5 GHz BaseStation
BRAND: Ubiquiti
airMAX PrismStation AC 5 GHz BaseStation
$299.00
Featuring a die-cast aluminum base and interchangeable horn antenna, the PrismStation 5AC with proprietary airMAX ac chipset and dedicated management Wi-Fi isolates beam communications between your devices. Ideal as an AP in crowded RF environments such as urban areas.
Out of stock
Brand
Ubiquiti
| Dimensions | 155 x 155 x 104 mm |
|---|---|
| Weight | 0.77 kg (1.70 lb) |
| Mounting Hardware Only | 0.79 kg (1.74 lb) |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| RF Connector | (1) GPS |
| LED | Power |
| Max. Power Consumption | 10W |
| Power Supply | 24V, 1A Gigabit PoE Adapter (Included) |
| Power Method | 24V Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Supported Voltage Range | 20 to 26VDC |
| Wind Loading | 31 N @ 200 km/h |
| Wind Survivability | 200 km/h |
| Operating Temperature | -40 to 70° C (-40 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Mounting | Pole-Mount (Kit Included) |
| ESD/EMP Protection | ± 24kV Contact/Air |
| Certifications | CE, FCC, IC |
| OPERATING FREQUENCY (MHZ) | — |
| U-NII-1 | 5150 – 5250 |
| U-NII-2A | 5250 – 5350 |
| U-NII-2C | 5470 – 5725 |
| U-NII-3 | 5725 – 5850 |
| MANAGEMENT RADIO (MHZ) | — |
| US/CA | 2412 – 2462 |
| Worldwide | 2412 – 2472 |
